Fully Brass Adjustable Spray Water Fountain Nozzles With Inside Mainfold 1/8" - 3"
Specifications
Stainless steel 304 Material:
| Model | Performance | Water Inlet | Water Outlet | Size | Weight |
| pressure (Kpa) | capacity (m3/h) | height (m) | coverage (m) | diameter (inch) | connection type | diameter (mm) | number (pcs) | height (mm) | max dia. (mm) | (kg) |
| ZWT65 | 70-200 | 12-18 | 3-10 | parabola or radial | 2 1/2" | external thr. | Ф20 * 1 | 235 | 80 | 1.46 |
| ZWT50 | 70-200 | 6-8 | 3-8 | 2" | Ф13 * 1 | 225 | 73 | 0.71 |
| ZWT40 | 70-150 | 4-6 | 3-8 | 1 1/2" | Ф12 * 1 | 212 | 60 | 0.55 |
| ZWT25 | 50-150 | 3-4 | 3-8 | 1" | Ф8 * 1 | 115 | 43 | 0.19 |
| ZWT20 | 50-150 | 1.5-3 | 1-8 | 3/4" | internal thr. | Ф7 * 1 | 100 | 37 | 0.15 |
| ZWT15 | 50-150 | 0.5-1.5 | 1-6 | 1/2" | internal thr. | Ф5 * 1 | 77 | 31 | 0.16 |
| * Can be made all in internal thread. | | | | | | | | |
Brass Material:
| Model | Performance | Water Inlet | Water Outlet | Size | Weight |
| pressure (Kpa) | capacity (m3/h) | height (m) | coverage (m) | diameter (inch) | connection type | diameter (mm) | number (pcs) | height (mm) | max dia. (mm) | (kg) |
| ZWT65 | 70-200 | 12-18 | 3-10 | parabola or radial | 2 1/2" | external thr. | Ф20 * 1 | 170 | 75 | 0.94 |
| ZWT50 | 70-200 | 6-8 | 3-8 | 2" | Ф18 * 1 | 150 | 60 | 0.6 |
| ZWT40 | 70-150 | 4-6 | 3-8 | 1 1/2" | Ф12 * 1 | 117 | 53 | 0.45 |
| ZWT25 | 50-150 | 3-4 | 3-8 | 1" | Ф8 * 1 | 112 | 43 | 0.26 |
| ZWT20 | 50-150 | 1.5-3 | 1-8 | 3/4" | internal thr. | Ф8 * 1 | 92 | 32 | 0.16 |
| ZWT15 | 50-150 | 0.5-1.5 | 1-6 | 1/2" | internal thr. | Ф6 * 1 | 83 | 27 | 0.12 |
| ZWT10 | 50-150 | 0.1-1.0 | 1-4 | 3/8" | external thr. | Ф5 * 1 | 67 | 20 | 0.07 |
| ZWT8 | 50-150 | 0.1-0.5 | 1-3 | 1/4" | Ф4 * 1 | 61 | 21 | 0.06 |
| ZWT6 | 30-80 | 0.05-0.4 | 1-2 | 1/8" | Ф4 * 1 | 60 | 16 | 0.04 |
Description:
Our brass adjustable spray fountain nozzles have many different types, can be with valve on it or without, can be accepted to make in clients' new design.
Have different spray height and spray width, using for many musical and dancing swing fountains, its the main fountain nozzle in water fountains.
Features:
1. Adjustable straight spray nozzle with single jet, direct spray .
2. The water pillar is crystal clear, crisp line and smooth.
3. The jet line can be adjusted in the range of ±10, with a flexible install way and can form various water shapes.
4. The adjustable straight nozzle can be widely used in fountains in any occasions, and is necessary nozzles for music fountain.
5. It has a ball-shaped connector which can be adjusted 15 along vertical direction.
6. The adjustable straight nozzles can be combined into different spraying results.
7. It will have a better effect when working with underwater lights.
It can match with:
1. Musical Fountain
2. Laser Water- Screen movie and water-screen ads
3. Water irrigation
4. Street, Plaza and Park lighting
5. Water Purification of River and Swimming Pool
6. Landscape Architecture Planning
7. All kinds of fountain equipments and Irrigation equipments
